Advance Series Central Vacuum Unit
Price range: $1,200.00 through $1,320.00
High Airwatt and quiet central vacuum unit with display and Interchange filtration options.
Advance Series Central Vacuum Units
Advance are the most innovative centralized vacuum units for domestic use. They are characterized by many advanced technical features, such as the Interchange system, which offers the choice between cyclonic filtering or bag filtration, so filter cleaning is not necessary.
Installation Area
- Surfaces between 300 and 500 m²
- Suitable for 1 user
- Pipe network Ø 50 mm / Ø 2”
- 220/240 Vac supply
- Non-continuous use for household dust vacuum
- Air exhaust to the outside
- Can be installed in utility rooms, service rooms, basements and balconies protected from bad weather.
Advance Selection Table
| Model | Recommended surfaces | Article | Recommended vacuum inlets | Number of users |
|---|---|---|---|---|
| Advance 300 | 300 m² | 111701 | 8 | 1 |
| Advance 500 | 500 m² | 111702 | 18 | 1 |
| Advance 600 | 800 m² | 111703 | 24 | 1 |
Main Features of the Product
- Interchange system for filtration options
- Integrated inlet
- Maintenance computer
- Energy saving vacuum unit
- Soft Start device
- CE marking
- IP protection degree
- Isolation class 1
- Max number of users: 1
Technical Features
Interchange system, filtration options
The Advance central units can be installed with two different options of filtration, to best suit customer requirements.
Cyclonic filtration: dust is separated from the air by the internal cyclonic effect and it falls into the dust collection bin. The conveyor cone prevents dust from returning to the filter, making surfaces dirty.
Bag filtration system with microfiber bag: the high filtration degree removes the need for filter cleaning. Once the bag is full, it is easily replaced.
Integral service inlet
It is possible to install a service inlet on vacuum unit bodies with cyclonic filtration, useful for cleaning surfaces and objects near the central vacuum unit. To enable service inlet use, just insert the vacuum hose inside it, without a micro-switch connection.
Low-maintenance filter
The innovative conical filter is made with polyester and aluminum fiber, water washable, class M certified, with a dedicated earth connection for static discharge. The conical shape helps dust fall into the bucket when the unit stops vacuuming.
Smart management software with 5 inch display
The Advance vacuum unit has a control board for maintenance management, connected to pressure detectors and set up to interact simply with the user. The display can show unit conditions and procedures to follow in case of malfunction.
The vacuum unit measures time and date, vacuum pressure, dust bin status for cyclonic filtration, power on/off, hours of work, hours of power on, and electrical consumption.
Breaker valve
The breaker valve allows air to enter inside the motor when the air inlet is closed, to avoid motor operation in critical conditions.
Measurements and Technical Data
| Item | Advance 300 | Advance 500 | Advance 600 |
|---|---|---|---|
| Article | 111701 | 111702 | 111703 |
| Air inlet / air discharge | Ø50 mm | Ø50 mm | Ø50 mm |
| Protection degree | IP44 | IP44 | IP44 |
| Supply | 220/240 Vac | 220/240 Vac | 220/240 Vac |
| Frequency | 50/60 Hz | 50/60 Hz | 50/60 Hz |
| Motor power | 1.7 kW | 2.0 kW | 2.2 kW |
| Maximum air flow | 245 m³/h | 260 m³/h | 275 m³/h |
| Depression Max | 325 mbar | 350 mbar | 360 mbar |
| Airwatt | 615 | 700 | 720 |
| Filtering surface | 7800 cm² | 7800 cm² | 7800 cm² |
| Dust container capacity | 30 L | 30 L | 30 L |
| Bag capacity | 20 L | 20 L | 20 L |
| Weight | 17 kg | 18 kg | 18 kg |
| Noise level lower than | 60 dB(A) | 61 dB(A) | 62 dB(A) |
Source: SYDMAY Catalog 2022, pages 4-13.
